System Map | Functions | Parameters |
Oxygen Generating System | Oxygen Flow | 0.5~5L/min |
Oxygen Concentration | 93% +3% | |
Oxygen Output Pressure | 0.04-0.07Mpa | |
Oxygen Number Display | YES | |
Nebulizer System | Nebulize Mode | YES |
Individual Nebulizer Outlet | YES | |
Display Method | On LED screen | |
Operating Way | By touch panel button | |
Accessories | Nebulize nozzle and mask | |
Nebulizing Particle Size | 3.6μm±25% | |
Screen Display System | Display Material | All by LED lights |
What Can Be Displayed ? | "Oxygen" light on | |
"Nebulize" light on | ||
"Oxygen Percentage" light on | ||
"Each Runing Time" light on | ||
"Accumulated Time" light on | ||
"Timer Setting Number" | ||
Operating System | Operating Panel | SmartTouch |
OXYGEN | Start to produce Oxygen | |
NEBULIZE | Start to run Nebulizer | |
TIMER "+" and "-" | Seting from 0 to 3 hours (15mins increase or decrease) | |
Safety System | Low Oxygen Alarm | Yes |
Oxygen Pressure Protection Alarm | Yes | |
Pressure Faulty Alarm | Yes | |
Power off Alarm | Yes | |
Compressor Faulty Alarm | Yes | |
Overheated Protection | Yes | |
Electrical System | Power Consumption | 420 W |
Auto Power off by timer | YES | |
Screen Sleep Mode | YES | |
Noise Level | <47dB(A) | |
Packing | Machine Body Size | 380x270x580mm |
Package Size | 440x340x650mm | |
Net Weight | 16.5kg | |
Gross Weight | 18.7kg | |
Body Material | ABS, Glaze | |
Optional Functions | Remote Control | Optional |
Voice Guide System | Optional |
